Induction Machine Offered By JKZ

Ultrasonic Frequency Induction Heating Machine

SWS series ultrasonic frequency induction heating equipment has a very wide application field. It can be used in automobile and motorcycle parts production, metal hot forging, metal heat treatment, hot bending and other applications.

Ultrasonic Frequency Induction Heating Machine Types

  • SWS-25A 15-30KHZ 25KW 36A Ultrasonic Frequency Induction Heating Machine

    SWS-25A

    15-30KHZ 25KW 36A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-40A 15-30KHZ 40KW 60A Ultrasonic Frequency Induction Heating Machine

    SWS-40A

    15-30KHZ 40KW 60A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-50A 15-30KHZ 50KW 76A Ultrasonic Frequency Induction Heating Machine

    SWS-50A

    15-30KHZ 50KW 76A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-65A 15-30KHZ 65KW 100A Ultrasonic Frequency Induction Heating Machine

    SWS-65A

    15-30KHZ 65KW 100A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-80A 15-30KHZ 80KW 125A Ultrasonic Frequency Induction Heating Machine

    SWS-80A

    15-30KHZ 80KW 125A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-120A 15-30KHZ 120KW 182A Ultrasonic Frequency Induction Heating Machine

    SWS-120A

    15-30KHZ 120KW 182A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-160A 15-30KHZ 160KW 250A Ultrasonic Frequency Induction Heating Machine

    SWS-160A

    15-30KHZ 160KW 250A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-200A 15-30KHZ 200KW 310A Ultrasonic Frequency Induction Heating Machine

    SWS-200A

    15-30KHZ 200KW 310A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...
  • SWS-250A 15-30KHZ 250KW 380A Ultrasonic Frequency Induction Heating Machine

    SWS-250A

    15-30KHZ 250KW 380A
    SWS series induction heater, JKZ designed a full digital control induction heating generator at the frequency range of 15~30KHz. It is designed with a maximum single machine power of 250KW and integra...

Advantages of Ultrasonic Frequency Induction Heating Machine


  • The output frequency range of the SWS series induction heating power supply is 15~30KHz, which is suitable for the overall heating of small and medium-sized workpieces. It has high heating efficiency and good temperature uniform effect.


  • Based on the optimized overall circuit design, this series of JKZ induction heating equipment is more energy-saving. Compared with traditional SCR induction heating equipment, it has obvious advantages such as higher operating frequency and good energy-saving effect.


  • Adoting a fully digital design, this series of induction heating equipment is stable and reliable. Customers can directly control the equipment through the optional touch screen. At the same time, they can also customize a variety of external control interfaces according to their own requirements such as the requirements for RS485 or other I/O. The module also accepts external PLC control requirements.


  • Standard SWS can be applied to wide voltage fluctuation (*360V~440V), and non-standard voltage power supply can also be customized according to the actual situation of customers.


  • Equipped with a condition monitoring system (CMS), the built-in monitoring system of SWS series can effectively monitor the temperature, current, voltage, water flow, etc. of the main components of the equipment through a single chip microcomputer. Problems like overvoltage, undervoltage, overtemperature, water shortage, phase failure, and overcurrent will all be easily detected in real time.


  • The induction equipment is equipped with an output isolation transformer to effectively ensure the safety of use.


Application of UHF Induction Heating Machine

1. Carbide saw blade size tooth welding

2. Welding and annealing of spectacle frames and parts

3. Welding of Jewelry Watches

4. Electronic industry (extremely thin wires, various electronic components, fine parts, soldering, silver soldering)

5. Electromechanical industry (fine metal joint silver brazing micro-motor shaft quenching and tempering)

6. Wire industry (wire annealing)

7. Tool welding, paper cutter, shoe blade edge quenching

8. Toy industry (tempering of spring metal plates)
