CX2030C High Frequency Induction Heating Machine

CX2030C 50-120KHZ 30KVA 23A High Frequency Induction Heating Machine

Name: CX2030C
Brand: Chengdu Jinkezhi Electronic Co., Ltd.

CX2030C 50-120KHZ high-frequency MOSFET type induction heater holds the output power of 15KW/30KVA. It is suitable for soldering, welding and quenching heating of small metal parts. Produced by a famous brand, MOSFET of our high frequency induction heater is quality reliable. With rich experience in producing induction heating units, JKZ has also equipped CX2030C with a mature design so as to ensure stable equipment performance. Having the functions of remote start/stop, CX2030C also has a remote power control system that can be designed according to customers' actual requirements. Thus, it is easy to combine the machine to work together with the production line.

Send Inquiry

Specifications of CX2030C High Frequency Induction Heating Machine

CX2030C 30 kva induction heater is a specialized industrial device used for heating and treating various materials through electromagnetic induction. The high-frequency 30kw induction heater machine operates on the principle of electromagnetic induction, where alternating current (AC) passes through a coil (inductor), creating a rapidly changing magnetic field. This magnetic field induces eddy currents within the electrically conductive workpiece placed within or near the coil, causing it to heat up.

Input voltage	3 Phases 380V±10% 50/60HZ
Input AC current	23A
Output power	30KVA
Output frequency	50-120KHZ
Duty cycle	100%
Power factor	≥95%
Cooling water pressure	0.1-0.15 MPa
Cooling water flow	≥1.0 m³/Hour

*Slide to find out more.

Advantage of CX2030C 30KW Induction Heater

Our 30 KW induction heater offers several advantages for various industrial heating and processing applications. Here are some of the key advantages:

1. Precision Heating: Induction heaters provide precise control over the heating process. The power output can be adjusted to achieve the desired temperature and heating rate, making it suitable for applications requiring precise temperature control.

2. Efficiency: Induction heating is highly efficient because it directly heats the workpiece or material, minimizing heat loss to the surroundings. The CX2030C 30 KVA induction heater can provide rapid and uniform heating, ensuring energy is used efficiently.

3. Versatility: A 30KW induction heater can be used for a wide range of applications, including brazing, welding, hardening, annealing, forging, and more. It can handle different materials, sizes, and shapes of workpieces.

4. Cost Savings: Efficient heating and precise control can lead to cost savings in terms of energy consumption, reduced scrap rates, and improved overall process efficiency.

Application of CX2030C High Frequency Induction Heating Machine

The CX2030C 30KW induction heater has a versatile range of applications, as indicated by the provided points:

1. Brazing of length 6~40mm carbide and other materials

This machine can be used for brazing operations, which involve joining different materials, such as carbide, with lengths ranging from 6 to 40mm. Brazing typically requires precise and controlled heating to melt a filler material and create strong joints.

2. Welding of Ø6~15mm copper pipe

Induction welding of the 30 KW induction heater offers a fast and efficient method for joining copper pipes, ensuring reliable connections.

3. Non-ferrous metal smelting

Smelting involves melting raw materials to extract the desired metal, and induction heating can provide the necessary high temperatures for this process.

4. Forging heating of Ø8-10mm steel rod

Forging heating is a crucial step in shaping steel rods. The CX2030C 30 KVA induction heater can efficiently heat steel rods with diameters of 8 to 10mm, making it suitable for various forging applications, including blacksmithing and industrial forging.
