SWS-80A 15-30KHZ 80KW 125A Ultrasonic Frequency Induction Heating Machine

SWS-80A ultrasonic frequency induction heater's maximum output power is at 80KW, and its frequency range is 15-30KZ. With the inside monitoring system, SWS-80A can indicate the system's working faulty situations like over voltage/low voltage/lack of water/over temperature/over current/lack of phase timely. Thus, just like any other induction heating device in this series, SWS-80A can also realize self-protection if there occurs a sudden peak voltage or current.


Send Inquiry

Functions of SWS-80A Ultrasonic Frequency Induction Heating Machine

SWA-80A, as a high-quality metal heating machine, adopts a modular design. Its inner structure is simple and stable with tinned copper materials. It will be simple for the users to do the installation, spare parts replacement and regular maintenance.

This induction generator with the external remote control system can realize the function of remote control of the start/stop, adjustment of the power output, and controlling of the temperature and heating time. These functions make induction heating equipment more convenient in the usages of different industries. You can find the existence of our SWS-80A in various occasions as the steel rod forging heating, fasteners manufacturing, auto parts surface layer hardening, spring wire annealing machine, and non-ferrous metal melting like copper, aluminium, gold, silver.


Specifications of SWS-80A Ultrasonic Frequency Induction Heating Machine

Input voltage

3 Phases 380V±10%  50/60HZ

Input AC current

125A

Output power

80KW

Output frequency

15-30KHZ

Duty cycle

100%

Power factor

≥95%

Cooling water pressure

0.2-0.3 MPa

Cooling water flow

≥5.5 m³/Hour


*Slide to find out more.

Application of SWS-80A Ultrasonic Frequency Induction Heating Machine

  • Forging: suitable for forging of steel, stainless steel, copper and aluminum Ø20mm-Ø35mm

  • Hardening: suitable for hardening depth of 2-5 mm of Ø40-Ø70mm steel bar

  • Melting: suitable for smelting 50-80kg of non-ferrous metals
